Features



  1. Adjustable EN size 2-4
  2. Suitable for door widths up to 1100mm
  3. Maximum door weight tested up to 130kg
  4. Non-handed solution
  5. Concealed solution to help achieve a sleek door profile
  6. Vandalism-resistant
  7. Adjustable closing and latching speed
  8. Incorporates cam-action technology, which is an efficient mechanism that reduces resistance when opening the door.
  9. Backcheck prevents over swinging
  10. Complies to the highest international standards
  11. Tested to 500,000 cycles



Specifications

Door Type

Timber or Metal

Door Size

Max width: 1100mm

Max weight: 130kg

Application

Regular – pull side mount

Stop face – push side mount

Adjustment Controls

Closing speed, Latching speed, Closing force, Hold open, Back check

Strength

EN 2-4 adjustable



Downloads

Briton C3024 Series Concealed Door Closer Datasheet

Filename
Briton C3024 Concealed Door Closer Datasheet 0125.pdf
Size
185 KB
Format
application/pdf

Briton C3024 Series Concealed Door Closer Installation Instructions

Filename
Briton C3024 Series Door Closer Installation Instruction 1223.pdf
Size
511 KB
Format
application/pdf

2310 Allegion Door Hardware Maintenance

Filename
2310 Allegion Door Hardware Maintenance.pdf
Size
109 KB
Format
application/pdf

2310 Caring for Door Hardware Finishes

Filename
2310 Allegion Caring for Door Hardware Finishes.pdf
Size
84 KB
Format
application/pdf

Briton C3024 Series Concealed Door Closer Datasheet

Filename
Briton C3024 Concealed Door Closer Datasheet 0125.pdf
Size
185 KB
Format
application/pdf

No selected resources found. Try another category.

Briton C3024 Series Concealed Door Closer Installation Instructions

Filename
Briton C3024 Series Door Closer Installation Instruction 1223.pdf
Size
511 KB
Format
application/pdf

No selected resources found. Try another category.

2310 Allegion Door Hardware Maintenance

Filename
2310 Allegion Door Hardware Maintenance.pdf
Size
109 KB
Format
application/pdf

2310 Caring for Door Hardware Finishes

Filename
2310 Allegion Caring for Door Hardware Finishes.pdf
Size
84 KB
Format
application/pdf

Providing safe and functional environments

For over 100 years the Briton brand has been synonymous with the very best in door controls and exit hardware.

It is a well-earned reputation based on a tradition of producing high quality, highly engineered products, designed to stand the test of time and to endure the rigours of life on buildings throughout the world.

Briton 2400 Series Concealed Cam Action Door Closer
