Features



  1. Wall-mounted installation - Provides a secure and stable mounting point for the magnetic holder, while also helping to save space.
  2. Strong and reliable magnetic hold - Engineered with high-quality materials, this magnetic holder provides a strong and consistent hold to keep doors open as needed, ensuring long-lasting performance and reliability.
  3. Equipped with an intuitive release button - In the event of a fire or emergency, it facilitates quick release, ensuring safety and compliance with fire safety regulations. Additionally, it allows users to easily disengage the magnetic hold, enabling the door to close when needed.
  4. Adjustable armature plate - Enables easy alignment and installation on various door types and sizes, ensuring optimal magnetic contact and holding force.
  5. Versatile - Designed to fit various door types and profiles, including fire escape doors in large-scale buildings.



Specifications

Holding Strength

  30 - 50 lbs

Voltage/ Current

12V AC/DC: 52/60mA

24V AC/DC: 27/31mA

120VAC: 24mA

Size (mm)

Magnet assembly: 116.5(H) / 69.5(W) / 77(D)

Strike plate: 42(L) / 65.3(W) / ∅54(D)





Downloads

Schlage DH507 Series Magnetic Holder with Release Button Datasheet

Filename
Schlage DH507 Magnetic Holder Datasheet 0924.pdf
Size
1 MB
Format
application/pdf
