Features



  • Heavy-duty - Capable of supporting door weights up to 250kg.
  • Convenient - Features a push and go function for easy operation.
  • Self-closing - In the event of a power failure, the operator will function as a normal door closer.
  • One key recovery - Quick and easy restoration of the door closer to its default settings, simplifying maintenance and ensuring optimal performance
  • Designed with end user’s safety in mind - If the operator encounters an object and lacks a safety sensor, it will automatically reverse in the opposite direction.



Specifications

Series Name

SW250

Power / Power Consumption

220V/50Hz; 110V/60Hz /  13W (standby); 87W (rated)

Max. Door Size

  • Max. door weight: 250kg - (900mm) push arm, 200kg - (900mm) pull arm
  • Max. door width: 1250mm - push arm, 1100mm - pull arm

Opening Angle

45° ~ 99°

Functions

Self-diagnostic, push and go, synchronization, self-closing, manual push open, automatic reverse function, overheating protection, overload protection, safe voltage, fire alarm signal

Extended Spindle Sizes (mm)

33 / 55 / 85
